ALBA gunboat (1940 / 1941)





Beli Orao 1940

Ships


Name No Yard No Builder Laid down Launched Comp Fate
Alba (ex-Бели Орао [Beli Orao]), 9.1943- Zagabria     CRDA, Trieste   3.6.1939 1940 // 4.1941 to Yugoslavia 12.1943 (Бели Орао [Beli Orao])


Technical data


Displacement standard, t567
Displacement full, t660
Length, m

60.1 pp 65.0 oa

Breadth, m

8.08

Draught, m

2.84

No of shafts

2

Machinery

2 Sulzer diesels

Power, h. p.

1900

Max speed, kts

18

Fuel, tdiesel oil
Endurance, nm(kts)
Armament

2 x 1 - 40/67 Škoda, 2 x 1 - 13.2/76

Complement


Standard scale images


as <i>Jadranka </i>1950s
as Jadranka 1950s


Graphics


Beli Orao 1940
Beli Orao 1940


Project history

Ex-Yugoslavian gunboat / Royal yacht, captured and commissioned by Italians.

Modernizations

None.

Naval service

After armistice ship was returned to Yugoslavia and served there till 1978.
