Courageuse 1919

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
FR56 (ex-Dédaigneuse)			F C de la Gironde, Bordeaux, France		1916	1917 // ---	captured incomplete by Germany 9.9.1943

Technical data

Displacement normal, t	310
Displacement full, t	410
Length, m	60.2
Breadth, m	7.20
Draught, m	2.90
No of shafts	2
Machinery	2 VTE, 2 Du Temple or Normand boilers
Power, h. p.	2200
Max speed, kts	17
Fuel, t	coal 85
Endurance, nm(kts)	2000(10)
Armament	2 x 1 - 100/45 M1897, 2 DCT, mechanical minesweeping gear
Complement	107

Standard scale images

Graphics

Project history

Ex-French aviso (ASW gunboat) scuttled in Toulon and raised in 1943. She was never commissioned by Italians and re-captured by Germans 9.9.1943.
