AQUILA torpedo boats (1882)
24T 1886
Ships
| Names | Builders | Completed | Losses | Transfers | Discarding |
|---|---|---|---|---|---|
Aquila, 1886- 23T Gabbiano, 1886- 24T |
Thornycroft, Cheeswick, UK: Aquila, Gabbiano |
1882: Aquila, Gabbiano |
none |
none |
1907: 23T, 24T |
Technical data
| Displacement normal, t | 34.5 |
|---|---|
| Displacement full, t | |
| Length, m | 29.2 |
| Breadth, m | 3.28 |
| Draught, m | 1.47 |
| No of shafts | 1 |
| Machinery | 1 VDE, 1 locomotive boiler |
| Power, h. p. | 475 |
| Max speed, kts | 20 |
| Fuel, t | coal |
| Endurance, nm(kts) | |
| Armament | 1 x 2 - 25/41 N, 2 - 350 TT (bow) |
| Complement | 11 |
Standard scale images
Aquila 1882
Graphics
24T 1886
Project history
3rd class TBs.
Modernizations
None.
Naval service
No significant events.
