ORESTE CAVALLARI patrol boats (1989-1991)
Walter Fachin
Ships
| Name | No | Yard No | Builder | Laid down | Launched | Comm | Fate |
|---|---|---|---|---|---|---|---|
| Oreste Cavallari | CP401 | CNR, Ancona | 1989 | in service (2019) | |||
| Renato Pennetti | CP402 | CNR, Ancona | 1990 | in service (2019) | |||
| Walter Fachin | CP403 | CNR, Ancona | 1990 | in service (2019) | |||
| Gaetano Magliano | CP404 | CNR, Ancona | 1991 | in service (2019) |
Technical data
| Displacement standard, t | |
|---|---|
| Displacement full, t | 130 |
| Length, m | 28.6 |
| Breadth, m | 6.20 |
| Draught, m | 2.00 |
| No of shafts | 2 |
| Machinery | 4 Isotta-Fraschini ID36 SS8V diesels |
| Power, h. p. | 3520 |
| Max speed, kts | 22 |
| Fuel, t | diesel oil |
| Endurance, nm(kts) | 1000 |
| Armament | 2 x 1 - 7.6/90 |
| Electronic equipment | Decca, nav. radars |
| Complement | 11 + 50 rescuees |
Graphics
Walter Fachin
Project history
Carry a 3.8t, 8.00x2.40x0.70m "daughter boat" for rescue work on ramp aft. Can be equipped to carry one 20mm AA. Have fin stabilizers.
Modernizations
None.
Naval service
No significant events.
