SHAHROKH patrols (1932)





Simurgh 1931

Ships


Name No Yard No Builder Laid down Launched Comp Fate
شاهرخ [Shahrokh]     CNR, Palermo, Italy 1930 26.7.1931 1932 captured by United Kingdom 25.8.1941 (Indian Nilam), returned 1946, discarded 1953
شَهباز [Shahbaz]     OCP, Naples, Italy 1930 12.9.1931 1932 captured by United Kingdom 25.8.1941 (Indian Hira), returned 1946, discarded 1953
كركس [Karkass]     CNR, Palermo, Italy 1930 24.8.1931 1932 captured by United Kingdom 25.8.1941 (Indian Moti), returned 1946, discarded 1946
سیمرغ [Simurgh]     CNR, Palermo, Italy 1930 3.8.1931 1932 captured by United Kingdom 25.8.1941 (Indian Lal), returned 1946, discarded 1953


Technical data


Displacement standard, t

331

Displacement full, t~360
Length, m

51.8 pp

Breadth, m

6.70

Draught, m

1.83

No of shafts

2

Machinery

2 Fiat diesels

Power, h. p.

900

Max speed, kts

15.5

Fuel, t

diesel oil

Endurance, nm(kts)3000(8)
Armament

2 x 1 - 76/40 Ansaldo 1917, 2 x 1 - 37/27 Maxim-Nordenfelt

Complement


Standard scale images


<i>Karkass </i>1940
Karkass 1940


Graphics


<i>Simurgh </i>1931
Simurgh 1931


Project history

Small ships intended for coastal patrol service. Both 76mm guns were placed on a forecastle.

Modernizations

1946, all (as rearmed in the RIM service): were armed with 1 x 1 - 76/40 HA/LA Mk IX, 1 x 1 - 20/70 Mk III

Naval service

Chahrokh and Simorgh 25.8.1941 were captured by boarding groups from Australian sloop Yarra at Khorramshahr, Chahbaaz and Karkass this day were captured by boarding groups from Indian sloop Lawrence at Bandar-Shapur. Subsequently all four were commissioned by RIM as Hira, Nilam, Moti and Lai and were used as training and patrol ships at Bombay. They were returned to Iran in 1946 and received former names.
