NAVYPEDIA


Shahid Absalan 2006

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
فتح [Fath], 2007- شهید مهدوی [Shahid Mehdavi]	301, later- 313-1		Zhanjiang SY, China			9/1994	IRGC, in service (2019)
نصر [Nasr], 2007- شهید کرد [Shahid Kord]	302, later- 313-2		Zhanjiang SY, China			9.1994	IRGC, in service (2019)
صاف [Saf], 2007- شهید شافیحی [Shahid Shafihi]	303, later- 313-3		Zhanjiang SY, China			9.1994	IRGC, in service (2019)
را'د [Ra'd], 2007- شهید توسلی [Shahid Towsali]	304, later- 313-4		Zhanjiang SY, China			9.1994	IRGC, in service (2019)
فجر [Fajr], 2007- شهید حجت زاده [Shahid Hejat Zadeh]	305, later- 313-5		Zhanjiang SY, China			9.1994	IRGC, in service (2019)
شمس [Shams], 2007- شهید دارا [Shahid Dara]	306, later- 313-6		Zhanjiang SY, China			3.1996	IRGC, in service (2019)
مه'رج [Meraf], 2007- شهید آبسالان [Shahid Absalan]	307, later- 313-7		Zhanjiang SY, China			3.1996	IRGC, in service (2019)
فلق [Falaq], 2007- شهید بحثی ریسی [Shahid Rahisi Raisi]	308, later- 313-8		Zhanjiang SY, China			3.1996	IRGC, in service (2019)
حدید [Hadid], 2007- شهید گلزام [Shahid Golzam]	309, later- 313-9		Zhanjiang SY, China			3.1996	IRGC, in service (2019)
قدر [Qadr], 2007- شهید سهرابی [Shahid Sahrabi]	310, later- 313-10		Zhanjiang SY, China			3.1996	IRGC, in service (2019)

Technical data

Displacement standard, t	170
Displacement full, t	205
Length, m	38.6
Breadth, m	6.80
Draught, m	2.70
No of shafts	3
Machinery	3 diesels
Power, h. p.	8000
Max speed, kts	35
Fuel, t	diesel oil
Endurance, nm(kts)	800(30)
Armament	2 x 2 Noor SSM (4 C-802), 1 x 2 - 30/71 AK-230, 1 x 2 - 23/87 ZU-23-2
Electronic equipment	SR-47A, RM-1070A, type 341 radars
Complement	28

Standard scale images

Graphics

Project history

Chinese 'Hudong' class designed on the standard 'Huangfen' class hull, based on Soviet project 205. Ordered in December 1991.

Modernizations

None.

Naval service

No significant events.
