NAVYPEDIA


Pulau Roti Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Pulau Rau	501	4868	Abeking & Rasmussen, Lemwerder, West Germany			1954-1957	stricken 1974
Pulau Roma	502	4870	Abeking & Rasmussen, Lemwerder, West Germany			1954-1957	stricken 1974
Pulau Rass	503	4869	Abeking & Rasmussen, Lemwerder, West Germany			1954-1957	stricken 1969
Pulau Roti	504	4871	Abeking & Rasmussen, Lemwerder, West Germany			1954-1957	stricken 1969
Pulau Rupat	505, 1975- 708	4872	Abeking & Rasmussen, Lemwerder, West Germany			1954-1957	stricken 1981
Pulau Rangsang	506	4959	Abeking & Rasmussen, Lemwerder, West Germany			1954-1957	stricken 1974
Pulau Rindja	507	4961	Abeking & Rasmussen, Lemwerder, West Germany			1954-1957	stricken 1975
Pulau Rempang	508	4960	Abeking & Rasmussen, Lemwerder, West Germany			1954-1957	stricken 1974
Pulau Rengat	509, 1975- 707		Abeking & Rasmussen, Lemwerder, West Germany			1954-1957	stricken 1979
Pulau Rusa	510		Abeking & Rasmussen, Lemwerder, West Germany			1954-1957	stricken 1974

Technical data

Displacement standard, t	139
Displacement full, t
Length, m	39.3
Breadth, m	5.70
Draught, m	1.50
No of shafts	2
Machinery	2 MAN diesels
Power, h. p.	2800
Max speed, kts	24.6
Fuel, t	diesel oil
Endurance, nm(kts)
Armament	1 x 1 - 40/60 Mk 3, 2 x 1 - 20/70 Mk 10, mechanical minesweeping gear
Electronic equipment	nav. radar?
Complement	26

Standard scale images

Graphics

Project history

Modified design of German WWII-era 'R' type inshore minesweeper. Had a light metal framework covered with wood.

Modernizations

None.

Naval service

No significant events.

Many thanks to Wolfgang Stöhr for additional information on this page.
