Laplace Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Laplace	Q111		Arsenal de Rochefort	1913	12.8.1919	1921	stricken 1937
Lagrange	Q112		Arsenal de Toulon	1913	31.5.1917	2.1918	stricken 7.1935
Regnault	Q113		Arsenal de Toulon	1913	25.6.1924	1924	stricken 1937
Romazotti	Q114		Arsenal de Toulon	1914	31.3.1918	9.1918	stricken 7.1935

Technical data

Displacement standard, t
Displacement normal, t	920 / 1318
Length, m	75.2
Breadth, m	6.30
Draught, m	3.60
No of shafts	2
Machinery	2 Sulzer diesels / 2 electric motors
Power, h. p.	2600 / 1640
Max speed, kts	16.5 / 11
Fuel, t	diesel oil
Endurance, nm(kts)	4300(10) / 125(5)
Armament	2 x 1 - 75/35 M1897, 8 - 450 TT (2 bow, 4 inboard, 2 ext cradles; 10)
Complement	47
Diving depth operational, m	50

Standard scale images

Graphics

Project history

Largest and strongest submarines of French Navy fleet, represented an improved version of Dupuy de Lôme. Under the project they should have 4000hp steam turbines for surface cruising, but during building were equipped by Sulzer diesels.

Modernizations

None.

Naval service

No significant events.
