ARMIDE submarines (1916 - 1917)





Amazone after war Many thanks to Wolfgang Stöhr for additional information on this page.

Ships


Name No Yard No Builder Laid down Launched Comp Fate
Armide (ex-14-go) SD2   Schneider, Chalon-sur-Saône 1912 7.1915 6.1916 stricken 7.1932
Antigone (ex-PS) SD3   Schneider, Chalon-sur-Saône 1912 10.1916 1.1917 stricken 8.1935
Amazone (ex-X), 4.1928- Amazone II SD4   Schneider, Chalon-sur-Saône 1913 8.1916 6.1917 stricken 7.1932


Technical data


Displacement standard, t
Displacement normal, t

457 / 670

Length, m

56.2

Breadth, m

5.20

Draught, m

3.00

No of shafts

2

Machinery

2 Schneider-Carels diesels / 2 electric motors

Power, h. p.

2200 / 900

Max speed, kts

17.5 / 11

Fuel, t

diesel oil

Endurance, nm(kts)2600(11) / 160(5)
Armament

Amazone: 4 - 450 TT (bow, 6), 1 x 1 - 75/35 M1897

Antigone: 4 - 450 TT (bow, 6), 1 x 1 - 47/50 M1902

Armide: 6 - 450 TT (4 bow, 2 side drop-collars, 8), 1 x 1 - 47/50 M1902

Complement31
Diving depth operational, m


Standard scale images


<i>Amazone</i> 1917
Amazone 1917


Graphics


<i>Amazone</i> after war <i>Many thanks to Wolfgang Stöhr for additional information on this page.</i>
Amazone after war Many thanks to Wolfgang Stöhr for additional information on this page.


Project history

Double-hulled submarines, designed by M. Laubeuf, laid by Japanese (No 14, future Armide) and Greek orders (two others). First two, ex-Greek submarines, requisitioned 3.6.1915, Armide was requisitioned 30.5.1917.

Modernizations

None.

Naval service

No significant events.

Many thanks to Wolfgang Stöhr for additional information on this page.
