NAVYPEDIA


Ruissalo 1979

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Ruissalo	53		Laivateollisuus, Turku	1958	16.6.1959	8.1959	stricken 1994
Raisio	54		Laivateollisuus, Turku	1958	2.7.1959	9.1959	stricken 2004
Röytta	55		Laivateollisuus, Turku	1958	2.6.1959	10.1959	stricken 2005

Technical data

Displacement standard, t	110
Displacement full, t	130
Length, m	32.0
Breadth, m	6.00
Draught, m	1.80
No of shafts	2
Machinery	2 MTU diesels
Power, h. p.	2500
Max speed, kts	15
Fuel, t	diesel oil
Endurance, nm(kts)
Armament	1 x 1 - 40/60 Bofors 315, 1 x 1 - 20/70 Mk 7, 2 x 5 RBU-1200 ASWRL, mechanical minesweeping gear
Electronic equipment	Decca radar, sonar
Complement	20

Standard scale images

Graphics

Project history

Development of previous design. Also can be used as minesweepers.

Modernizations

1976, Ruissalo; 1980, Raisio, Röytta: - 1 x 1 - 40/60, 1 x 1 - 20/70; + 2 x 2 - 23/87 ZU-23-2

Naval service

No significant events.

1979
