J1 JYLHÄ motor torpedo boats (1939/1943)







Ships


Names Builders Completed Losses Transfers Discarding

J1 Jylhä (ex-MAS526)

J2 Jyry (ex-MAS527)

J3 Jyske (ex-MAS528)

J4 Jymy (ex-MAS529)

Baglietto, Varazze, Italy: J1 Jylhä, J2 Jyry, J3 Jyske, J4 Jymy

1939 // 6.1943: J1 Jylhä, J2 Jyry, J3 Jyske, J4 Jymy

none

none

1961: J1 Jylhä, J2 Jyry, J3 Jyske, J4 Jymy



Technical data


Displacement standard, t

22

Displacement full, t

25.2

Length, m

18.7

Breadth, m

4.60

Draught, m

1.50

No of shafts

2

Machinery

2 Isotta-Fraschini petrol engines / 2 Alfa Romeo cruising petrol engines

Power, h. p.

2300 / 100

Max speed, kts

42 / 6

Fuel, t

petrol 1.25

Endurance, nm(kts)
Armament

1 x 1 - 20/65 Breda 1939, 1 x 1 - 13.2/76, 2 - 450 TT, 6 DC

Complement

10



Standard scale images


<i>J1 Jylhä</i> 1942
J1 Jylhä 1942


Graphics





Project history

Italian MTBs of Baglietto class 500. Wooden-hulled. In 1942 they were transferred by Italians to Ladoga lake. 5.6.1943 they were bought by Finns. Under peace treaty with the USSR these boats had TTs demounted and served later as patrols.

Modernizations

1945, all: were reclassified as motor gunboats with armament consisted of 1 x 1 - 20/65 Breda, 1 x 1 - 13.2/76.

Naval service

No significant events.
