NAVYPEDIA


589 2006

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
pr. 1400: 506 pr. 1400M: 508 511 521, 522 pr. 1400ME 531, 532 535-538 541 546 550 - 555 568 - 571 579 582 589 599	More, Feodosiya, USSR: 506, 508, 511, 521, 522, 531, 532, 535 - 538, 541, 546, 550-555, 568 - 571, 579, 582, 589, 599	1971: 506 1974: 508 1975: 511, 521, 522, 531 1976: 532, 535 1977: 536, 537 1979: 538, 541 1980: 546, 550 - 554 1984: 555, 568, 569 1985: 570, 571, 579, 582 1989: 589, 599	none	none	late 1990s: 550, 553, 569, 570 2001: 506, 511, 521 2013: 535, 536, 551, 554, 571, 582 2018: 522 in service (2019): 508, 531, 532, 537, 538, 541, 546, 552, 555, 568, 579, 589, 599

Technical data

Displacement standard, t	pr. 1400, 1400M: 36 pr. 1400ME: 37
Displacement full, t	40
Length, m	23.8
Breadth, m	5.15
Draught, m	1.00
No of shafts	2
Machinery	pr. 1400: 2 M-401 diesels pr. 1400M: 2 M-401B diesels pr. 1400ME: 2 M-401BT diesels
Power, h. p.	2000
Max speed, kts	29
Fuel, t	diesel oil
Endurance, nm(kts)	pr. 1400, 1400ME: 450(13) pr. 1400M: 400(12)
Armament	pr. 1400: 1 x 2 - 14.5/89 or 1 x 2 - 12.7/79 pr. 1400M: 1 x 2 - 12.7/79 or 1 x 2 - 14.5/89 or (1 x 2 - 14.5/89, 1 x 2 - 12.7/79) pr. 1400ME: 1 x 2 - 12.7/79 or 2 x 2 - 12.7/79 or 1 x 2 - 14.5/89 or 2 x 2 - 14.5/89
Electronic equipment	Lotsiya or Liman or MR-241 Pechora-1 radar
Complement	9

Standard scale images

Graphics

Project history

Soviet project 1400, 1400M and 1400ME patrol boats.

Modernizations

None.

Naval service

No significant events.
