CHINA
AMPHIBIOUS SHIPS AND CRAFT
G3806 landing craft (1975)
Type 271 variant 2008
Ships
| Name | No | Yard No | Builder | Laid down | Launched | Comp | Fate |
|---|---|---|---|---|---|---|---|
| G3806 | Qingdao SY | 12/1972 | 9.1975 | 30.11.1975 | in service (2019) |
100 - 1000 t displacement/ BRT tonnage vessels
Technical data
| Displacement standard, t | 400 |
|---|---|
| Displacement normal, t | 500 |
| Length, m | 54.0 |
| Breadth, m | 9.20 |
| Draught, m | 1.70 |
| No of shafts | 2 |
| Machinery | 2 MAN 6300ZC diesels |
| Power, h. p. | 1200 |
| Max speed, kts | 13 |
| Fuel, t | diesel oil |
| Endurance, nm(kts) | 1000(10) |
| Armament | 2 x 2 - 14.5/89 |
| Military load | 3 main battle tanks or 4 trucks or 300 troops or 150 t of cargo |
| Electronic equipment | radar |
| Complement | 36 |
Standard scale images
similar Type 271IID 2010
Graphics
Type 271 variant 2008
Project history
Second variant of Type 271, type 271II. Correct number of ships built is unknown. Army service.
Modernizations
None.
Naval service
No significant events.
