No5220 fast attack craft (torpedo) (1952-1960)







Ships


Names Builders Commissioned Losses Transfers Discarding

55 boats (5220-... series)

Wuhu SY

Chuangxin SY

1952-1960: 55 boats

none

Albania, 1965: 6 boats

North Korea: some boats

North Vietnam: some boats

Bangladesh, 1983: 4 boats

1980s - 1995: all

1989:  81 were in service



Technical data


Displacement standard, t

19

Displacement full, t

23

Length, m

19.3

Breadth, m

3.43

Draught, m

0.77

No of shafts

2

Machinery

2 M-50-2 diesels

Power, h. p.

2000

Max speed, kts

50

Fuel, t

diesel oil

Endurance, nm(kts)

450(35)

Armament

1 x 2 - 14.5/93, 2 x 1 - 450 TT, 6 DC

Electronic equipment

Zarnitsa radar

Complement

7



Standard scale images


1955
1955


Graphics





Project history

Chinese-built copy of Soviet Project 123K.

Modernizations

None.

Naval service

No significant events.

Ivan Gogin, 2015
