NAVYPEDIA


Mondolkiri 1997

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comm	Fate
មណ្ឌលគិរី [Mondolkiri]	51, later- 1131	199	Almaz, Leningrad, USSR			10.1985	in service (2019)
	52, later- 1132	205	Almaz, Leningrad, USSR			1986	discarded 2015
	53, later- 1133	206	Almaz, Leningrad, USSR			11.1987	discarded 2015
រតនគិរ [Ratanakiri]	54, later- 1134	207	Almaz, Leningrad, USSR			11.1987	in service (2019)

Technical data

Displacement standard, t	211
Displacement full, t	245
Length, m	40.0
Breadth, m	7.91
Draught, m	1.96
No of shafts	3
Machinery	3 M-504B diesels
Power, h. p.	15000
Max speed, kts	36
Fuel, t	diesel oil
Endurance, nm(kts)	1910(11)
Armament	2 x 2 - 30/71 AK-230, 2 DCR (12)
Electronic equipment	4Ts-30-125, Ksenon radars
Complement	19

Standard scale images

Graphics

Project history

Soviet export project 02059, version of project 205P Border Guard patrol boat without ASW abilities.

Modernizations

1996, Mondolkiri: diesels were replaced by 3 Caterpillar (14000hp, 36kts, 700(20)nm); - 2 x 2 - 30/71, 4Ts-30-125, Ksenon radars; + 2 x 1 - 40/70 Breda-Bofors 564, 2 x 1 - 14.5/93, Decca BridgeMaster, Decca 1226 radars

1997, Ratanakiri: diesels were replaced by 3 Caterpillar (14000hp, 36kts, 700(20)nm); - 2 x 2 - 30/71, 4Ts-30-125, Ksenon radars; + 1 x 1 - 40/70 Breda-Bofors 564, 1 x 2 - 23/87 ZU-23-2, 2 x 1 - 14.5/93, Decca BridgeMaster, Decca 1226 radars

2010s, Mondolkiri: - 1 x 1 - 40/70; + 1 x 2 - 23/87 ZU-23-2

Naval service

No significant events.

© Ivan Gogin, 2019
