RKA-20 missile attack craft (project 205) (1965-1966/1971), RKA-23 missile attack craft (project 205U) (1960s-1970s/1977-1984)





Buria 2002

Ships


Name No Yard No Builder Laid down Launched Comp Fate Modification
РКА-20 [RKA-20] (ex-Р-30 [R-30]), 12.1985- Смерч [Smerch] 113, 2005- 107 464 Primorskiy Yd, Leningrad, USSR     1965 // 4.1971 stricken 6.2008 Project 205
РКА-21 [RKA-21] (ex-Р-73 [R-73]), 12.1985- Гръм [Grum] 112, 2005- 106 439 5 Yd, Leningrad, USSR     1965 // 4.1971 stricken 2012-15 Project 205
РКА-22 [RKA-22] (ex-Р-176 [R-176]), 12.1985- Буря [Buria] 103, 2005- 105   Primorskiy Yd, Leningrad, USSR     1966 // 4.1971 stricken 2012-15 Project 205
РКА-23 [RKA-23] (ex-Р-169 [R-169]), 1981- РКА-13 [RKA-13], 12.1985- Ураган [Uragan] 102   USSR     1960s-1970s // 2.1977 stricken 2012-15 Project 205U
РКА-11 [RKA-11] (ex-Р-496 [R-496]), 12.1985- Светкавици [Svetkavitsi] 101, 1990- 104, 2005- 103   USSR     1960s-1970s // 1.1982 stricken 2012-15 Project 205U
РКА-12 [RKA-12] (ex-Р-255 [R-255]), 12.1985- Тайфун [Tayfun] 111, 2005- 104 469 5 Yd, Leningrad, USSR     1965 // 1984 stricken 6.2008 Project 205U


Technical data


Displacement standard, t

pr. 205: 184

pr. 205U: 192

Displacement full, t

pr. 205: 226

pr. 205U: 235

Length, m

38.6

Breadth, m

7.60

Draught, m

1.84

No of shafts

3

Machinery

3 M-504B diesels

Power, h. p.

15000

Max speed, kts

42

Fuel, t

diesel oil

Endurance, nm(kts)

1800(14)

Armament

pr. 205: 4 x 1 P-15/P-15T SSM (4 P-15/P-15T), 2 x 2 - 30/71 AK-230

pr. 205U: 4 x 1 P-15U SSM (4 P-15U), 2 x 2 - 30/71 AK-230

Electronic equipment

MR-101 Rangout, MR-104 Rys' radars

Complement

pr. 205: 28

pr. 205U: 29



Standard scale images


<i>Smerch </i>1985
Smerch 1985
<i>Uragan </i>1985
Uragan 1985


Graphics


<i>Buria </i>2002
Buria 2002
<i>Grum </i>2002
Grum 2002


Project history

Former Soviet project 205 and project 205U FAC(M).

Modernizations

None.

Naval service

No significant events.
