Alagoas 1918

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Amazonas	1		Yarrow, Scotstoun, UK	1908	21.11.1908	1909	stricken 1931
Pará	2		Yarrow, Scotstoun, UK	1908	14.7.1908	1909	stricken 1933
Piauí	3		Yarrow, Scotstoun, UK	1908	7.9.1908	12.1909	stricken 7.1944
Rio Grande do Norte	4		Yarrow, Scotstoun, UK	1908	1909	1909	stricken 7.1944
Paraíba	5		Yarrow, Scotstoun, UK	1908	18.5.1909	1909	stricken 1944
Alagoas	6		Yarrow, Scotstoun, UK	1908	29.7.1909	1910	disarmed 1939
Sergipe	7		Yarrow, Scotstoun, UK	1908	25.5.1910	1910	stricken 7.1944
Paraná	8		Yarrow, Scotstoun, UK	1908	27.3.1910	1910	disarmed 10.1933
Santa Catharina	9		Yarrow, Scotstoun, UK	1908	26.10.1909	1910	stricken 7.1944
Mato Grosso	10		Yarrow, Scotstoun, UK	1908	23.1.1909	1909	stricken 9.1946

Technical data

Displacement normal, t	560
Displacement full, t
Length, m	73.2 pp
Breadth, m	7.16
Draught, m	2.42 mean
No of shafts	2
Machinery	2 4cyl VTE, 2 Yarrow boilers
Power, h. p.	8000
Max speed, kts	27
Fuel, t	coal 140
Endurance, nm(kts)	3700(14)
Armament	2 x 1 - 102/40 Vickers M, 4 x 1 - 47/40 3pdr Hotchkiss, 2 x 1 - 450 TT
Complement	130

Standard scale images

Graphics

Project history

10-ships Pará class was ordered by Yarrow under the 1907 programme. Intended for operation together with Baia class cruisers. On construction they were very close to British River class, differing by strengthened artillery. On trials all ships exceeded 27kts contract speed, fastest Paraná shown 28.736kts. Ships differed by excellent manoeuvrability: tactical diameter on full speed was about 340m, and time to a stop at full astern from full ahead was about 30s.

Modernizations

None.

Naval service

No significant events.
