LP01 patrol boats (1991-1995)
2000
Ships
| Names | Builders | Commissioned | Losses | Transfers | Discarding |
|---|---|---|---|---|---|
LP01 Timbiras (ex-P8005) LP02 (ex-P8006) LP03 Mucuripe (ex-P8004) LP04 (ex-P8007) LP05 Rio (ex-P8002) LP07 Espadarte (ex-P8003) |
Estaleiro do Sul, Porto Alegre: LP01-05, 07 |
1991: LP01-04 1995: LP05, 07 |
none |
none |
2010s: LP02, 04 in service (2019): LP01, 03, 05, 07 |
Technical data
| Displacement standard, t | 31 |
|---|---|
| Displacement full, t | 37 |
| Length, m | 17.5 pp 20.9 oa |
| Breadth, m | 5.18 |
| Draught, m | 1.45 |
| No of shafts | 2 |
| Machinery | 2 MTU 8V396 TB83 diesels |
| Power, h. p. | 2000 |
| Max speed, kts | 27 |
| Fuel, t | diesel oil 5 |
| Endurance, nm(kts) | 600(15) |
| Armament | 2 x 1 - 12.7/90 |
| Electronic equipment | Decca RM1070A radar |
| Complement | 8 |
Graphics
2000
Project history
Tracker II type.
Modernizations
None.
Naval service
No significant events.
