Madhumati 2012

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
মধুমতি [Madhumati]	P911		Hyundai, Ulsan, South Korea			18.2.1998	in service (2020)

Technical data

Displacement standard, t	600
Displacement full, t	635
Length, m	60.8
Breadth, m	8.00
Draught, m	2.70
No of shafts	2
Machinery	2 SEMT-Pielstick 12PA6 V280MPC diesels
Power, h. p.	9600
Max speed, kts	24
Fuel, t	diesel oil
Endurance, nm(kts)	6000(15)
Armament	1 x 1 - 57/70 SAK-57 Mk 1, 1 x 1 - 40/70 Bofors 350, 1 x 1 - 20/90 GAM-B01, 2 x 1 - 12.7/90
Electronic equipment	SPN-753B, type 1007 radars, NA18L e/o system
Complement	43

Standard scale images

Graphics

Project history

South Korean 'Sea Dragon' class. Ordered in 1995 as first unit of the Coast Guard.

Modernizations

None.

Naval service

No significant events.
