NAVYPEDIA


Uttal 1998

Ships

Names	Builders	Commissioned	Losses	Transfers	Discarding
P8111 দুর্বার [Durbar] P8112 দূরান্ত [Duranta] P8113 দুর্ভেদ্য [Durvedya] P8114 দুর্দম [Durdam] P8141 উত্তাল [Uttal]	Wuhu SY, China or Chuangxin SY, China: P8111-8114, 8141	1965-1976 // 1983: P8111-8114 1965-1976 // 1992: P8114	none	none	2017: P8111-8114, 8141

Technical data

Displacement standard, t	68
Displacement full, t	80
Length, m	27.0
Breadth, m	6.50
Draught, m	1.80
No of shafts	4
Machinery	4 M50F-4 diesels
Power, h. p.	4800
Max speed, kts	36
Fuel, t	diesel oil
Endurance, nm(kts)	500(25)
Armament	2 x 1 Hai Ying-2 SSM (2 HY-2), 1 x 2 - 25/80 type 61
Electronic equipment	type 352 radar
Complement	17

Standard scale images

Graphics

Project history

Former Chinese type 024 FACs. Uttal was delivered in 1992 as a replacement for one of two boats badly damaged during the cyclone in April 1991 (but later repaired).

Modernizations

None.

Naval service

No significant events.
