U41 submarine (1918)





U41 1918 Many thanks to Wolfgang Stöhr for additional information on this page.

Ships


Name No Yard No Builder Laid down Launched Comp Fate
U41   87 CNT, Monfalcone 2/1917 11.11.1917 2/1918 to France 1920


Technical data


Displacement standard, t



Displacement normal, t

280 / 326

Length, m

38.5

Breadth, m

4.37

Draught, m

3.68

No of shafts

2

Machinery

2 Grazer diesels / 2 SSW electric motors

Power, h. p.

400 / 280

Max speed, kts

9.4 / 5.8

Fuel, t

diesel oil 27

Endurance, nm(kts)

4000(5) / 45(4)

Armament

1 x 1 - 75/27 G. L/30 K.16 BAG, 2 - 450 TT (bow, 4)

Complement

19

Diving depth operational, m

50



Standard scale images


similar <i>U27 </i>1917
similar U27 1917


Graphics


<i>U41 </i>1918 <i>Many thanks to Wolfgang Stöhr for additional information on this page.</i>
U41 1918 Many thanks to Wolfgang Stöhr for additional information on this page.


Project history

Modified Austrian license-built variant of the German UB II type. Ordered on 12 October 1915. The hull of U41 was lengthened by 77cm, to take the already delivered diesel built for U6, which had been lost.

Modernizations

None.

Naval service

U41 was allocated to France in 1920 and scrapped.

Many thanks to Wolfgang Stöhr for additional information on this page.
