Bosna 1917 Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Temes, 5.1917- Bosna		533	STT, Linz	1914	1915	7/1915	to Yugoslavia 5.1919 (Вардар [Vardar])
Sava		534	STT, Linz	1914	31.5.1915	9/1915	to Yugoslavia 1919 (Соча [Soča])

Technical data

Displacement normal, t	580
Displacement full, t
Length, m	62.0
Breadth, m	10.3
Draught, m	1.30
No of shafts	2
Machinery	2 VTE, 2 Yarrow boilers
Power, h. p.	1750
Max speed, kts	13.5
Fuel, t	coal 60
Endurance, nm(kts)	700(10)
Armour, mm	side: 40, deck: 25, CT: 50
Armament	1 x 2 - 120/42 G. L/45, 2 x 1 - 120/8 Haub. L/10, 2 x 1 - 66/24 G. L/26 K.15 BAK, 2 x 1 - 47/40 SFK L/44 (Skoda), 7 x 1 - 8.80
Complement	91

Standard scale images

Graphics

Project history

Development of the Enns class.

Ship protection

Machinery had 40mm vertical and 25mm horizontal protection.

Modernizations

None.

Naval service

31.12.1918 both were interned at Beograd and entered Yugoslavian Danube flotilla but later Soča was transferred to Romania as Bucovina. In January, 1919 Bosna was renamed Vardar. 15.4.1920 by results of division of Austro-Hungarian fleet ship was officially transferred to Yugoslavia.
