Warasdiner 1915 Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Warasdiner (ex-Lung Tuan)		440	STT, San Marco	3/1911	4/1912	9/1914	to Italy 1920

Technical data

Displacement normal, t	386
Displacement full, t	400
Length, m	67.1 pp 68.4 wl
Breadth, m	6.25
Draught, m	1.70 deep load
No of shafts	2
Machinery	2 4-cyl VTE, 4 Yarrow boilers
Power, h. p.	6000
Max speed, kts	30
Fuel, t	coal 90
Endurance, nm(kts)	500(28)
Armament	2 x 1 - 66/42 SFK L/45, 4 x 1 - 66/27 G. L/30 K.09 TAG/BAG, 2 x 2 - 450 TT
Complement	75

Standard scale images

Graphics

Project history

Originally ordered from STT by the Chinese government as Lung Tuan in 1911, and intended to be the prototype of a class of 12 boats, armed with 2 76mm/50 and 4 47mm(3pdr)/50 Armstrong guns and 1 twin 450mm TT. Launched in 1912 the Lung Tuan was taken over by the Austro-Hungarian Navy on 28 August 1914, renamed Warasdiner and rearmed to Austrian standards. None of her sister-ships was ever laid down.

Modernizations

1917-1918: - 2 x 1 - 66/42; + 2 x 1 - 75/27 G. L/30 K.16 BAG

Naval service

Warasdiner saw active wartime service, was ceded to Italy in 1920 and scrapped.

Many thanks to Wolfgang Stöhr for additional information on this page.
