15 1918 Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Python, 1910- 13		1060	Yarrow, Cubitt Town, UK	1898	11.4.1899	10/1899	to France 1920
Kígyó, 1910- 14		1059	Yarrow, Cubitt Town, UK	1898	11.4.1899	1/1900	to United Kingdom 1920
Boa, 1910- 15		1058	Yarrow, Cubitt Town, UK	1897	8/1898	1898	to France 1920
Cobra, 1910- 16		1057	Yarrow, Cubitt Town, UK	1897	9/1898	1898	to France 1920

Technical data

Displacement normal, t	132
Displacement full, t
Length, m	46.6 wl
Breadth, m	4.70
Draught, m	2.30
No of shafts	1
Machinery	1 VTE, 2 Yarrow boilers
Power, h. p.	2000
Max speed, kts	24.5
Fuel, t	coal 30
Endurance, nm(kts)
Armament	2 x 1 - 47/30 SFK L/33 H, 3 x 1 - 450 TT
Complement	21

Standard scale images

Graphics

Project history

Yarrow-built TBs, development of the Viper.

Modernizations

1914, 14: - 1 x 1 - 450 TT; + 1 seaplane

Naval service

No significant events.
