fighting ships of the world

K-U-K MARINE - AUSTRO-HUNGARIAN NAVY (AUSTRIA-HUNGARY)

TORPEDO SHIPS

NATTER torpedo boat (1896)

Natter 1896

Name Yard No Builder Laid down Launched Comp Fate
Natter, 1910- 18 577 Schichau, Elbing, Germany 1/1895 3/1896 11/1896 to United Kingdom 1920



Displacement normal, t

166

Displacement full, t



Length, m

47.3 wl

Breadth, m

5.30

Draught, m

2.80

No of shafts

1

Machinery

VTE, 2 Schulz-Thornycroft boilers

Power, h. p.

2200

Max speed, kts

24

Fuel, t

coal 30

Endurance, nm(kts)

2600(12)

Armament

2 x 1 - 47/30 SFK L/33 H, 3 x 1 - 450 TT

Complement

21

Ship project history: Schichau-built TB.

Modernizations: 1911: - 2 x 1 - 47/40, 1 x 1 - 450 TT

Naval service: After 1910 18 served as mobile torpedo battery at Pola.

No18 1914

Ivan Gogin, 2014
