Ulan 1906 Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Huszár		1171	Yarrow, Poplar, UK	9/1904	31.3.1905	9/1905	wrecked 3.12.1908
Ulan		349	STT, San Marco	9/1905	8.4.1906	9/1906	to Greece 1920 (Σμύρνη [Smyrni])
Streiter		350	STT, San Marco	10/1905	16.6.1906	12/1906	collision 16.4.1918
Wildfang		351	STT, San Marco	12/1905	29.8.1906	6/1907	sunk 4.6.1917
Scharfschütze		352	STT, San Marco	4/1906	5.12.1906	9/1907	to Italy 1920
Uskoke		353	STT, San Marco	9/1906	20.7.1907	12/1907	to Italy 1920
Huszár			Marinearsenal Pola	11/1909	20.12.1910	2/1911	to Italy 1920
Turul		11	Danubius, Fiume	7/1907	9.8.1908	12/1908	to Italy 1920
Pandur		12	Danubius, Fiume	8/1907	25.10.1908	1/1909	to France 1920
Csikós		13	Danubius, Fiume	2/1908	24.1.1909	11/1909	to Italy 1920
Réka		14	Danubius, Fiume	8/1908	28.4.1909	12/1909	to France 1920
Dinara		15	Danubius, Fiume	1/1909	16.10.1909	12/1909	to Italy 1920
Velebit		16	Danubius, Fiume	11/1908	24.7.1909	12/1909	to Italy 1920

Technical data

Displacement normal, t	389
Displacement full, t	414
Length, m	67.1 pp 68.4 wl
Breadth, m	6.25
Draught, m	1.90 deep load
No of shafts	2
Machinery	2 4-cyl VTE, 4 Yarrow boilers
Power, h. p.	6000
Max speed, kts	28
Fuel, t	coal 90
Endurance, nm(kts)	500(28)
Armament	1 x 1 - 66/42 SFK L/45, 7 x 1 - 47/40 SFK L/44 S, 2 x 1 - 450 TT
Complement	65 - 70

Standard scale images

Graphics

Project history

In 1904 the Austro-Hungarian Navy ordered a prototype 400t destroyer from Yarrow, together with a 200t torpedo boat. A further 11 units of the Yarrow destroyer type were built at the above mentioned domestic yards. By 1910 advances of international destroyer development had left this type under-armed, so they were up-gunned in 1912-13.

Modernizations

1912-13, all survived: - 7 x 1 - 47/40; + 5 x 1 - 66/27 G. L/30 K.09 TAG/BAG

1916-1918, Streiter, Uskoke, Pandur: - 1 x 1 - 66/42 SFK L/45; + 1 x 1 - 66/42 G. L/42 BAG

1916-1918, Ulan, Wildfang, Scharfschütze, Huszár, Turul, Csikós, Réka, Dinara, Velebit: - 1 x 1 - 66/42; + 1 x 1 - 75/27 G. L/30 K.16 BAG

Naval service

The first Huszár ran aground near Traste 3.12.1908 and sank, so a replacement unit was built at the Pola N Yd to maintain the full dozen. Although obsolete at the outbreak of war these boats saw extensive wartime service: Wildfang was mined 4.6.1917 W of Peneda Island; Streiter sank 16.4.1918 off Laurana after a collision with s/s Petka. All the others were ceded to Italy or France and were scrapped immediately, except Ulan, which went to Greece as the Smyrni, and was discarded in 1928.
