Patria Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comp	Fate
Patria		595	Laird, Birkenhead, UK		12/1893	1894	survey vessel 1921, stricken 1927

Technical data

Displacement normal, t	1029 trials
Displacement full, t
Length, m	76.2 pp 76.7 oa
Breadth, m	9.60
Draught, m	2.95 trials
No of shafts	2
Machinery	2 VTE, 4 locomotive boilers
Power, h. p.	5000
Max speed, kts	20.5
Fuel, t	coal 288
Endurance, nm(kts)
Armament	2 x 1 - 120/41 Armstrong T, 4 x 1 - 63/42 Nordenfelt, 2 x 1 - 47/42 Nordenfelt, 5 - 450 TT (1 bow, 4 beam)
Complement	100

Standard scale images

Graphics

Project history

Steel-hulled ship with flush deck. There were one fixed bow TT and four fixed main deck broadside TTs. On trials Patria made 20.55kts on 5074hp.

Modernizations

None.

Naval service

No significant events.
