GAGRY torpedo boat (1884)





Gagry

Ships


Names Builders Completed Losses Transfers Discarding

Гагры [Gagry], 4.1895- №254

Claparede, Paris, France: Gagry

1884: Gagry

none

none

1907: №254



Technical data


Displacement normal, t

78

Displacement full, t80
Length, m

36.8

Breadth, m

4.12

Draught, m

1.98 max

No of shafts

1

Machinery

1 VC, 1 locomotive boiler

Power, h. p.

600

Max speed, kts

17.8

Fuel, t

coal 12

Endurance, nm(kts)
Armament

1 x 1 - 37/20 Hotchkiss, 1 x 5 - 37/17 Hotchkiss, 2 - 381 TT (bow)

Complement18


Standard scale images


similar <i>Poti </i>1892
similar Poti 1892


Graphics


<i>Gagry</i>
Gagry


Project history

Three small masts and two funnels abreast. The TT were fixed in the bows.

Modernizations

None.

Naval service

No significant events.
