1970 Many thanks to Wolfgang Stöhr for additional information on this page.

Ships

Name	No	Yard No	Builder	Laid down	Launched	Comm	Fate
201/1, 1.1960- Adler	454, 1965- G-15/G-21	426	340 Yd, Zelenodolsk, USSR			12/1959	Board Guard 1965, stricken 4.1972
201/2, 1.1960- Sperber	413/421, 1965- G-41/G-43	427	340 Yd, Zelenodolsk, USSR			12/1959	Board Guard 1965, stricken 5.1975
201/3, 1.1960- Falke	434, 1965- G-16/G-41	428	340 Yd, Zelenodolsk, USSR			12/1959	Board Guard 1965, stricken 4.1972
201/4, 1.1960- Habicht	414/422, 1965- G-42/G-44	429	340 Yd, Zelenodolsk, USSR			12/1959	Board Guard 1965, stricken 10.1975
201/5, 1.1960- Reiher	451, 1965- G-17/G-42	430	340 Yd, Zelenodolsk, USSR			12/1959	Board Guard 1965, stricken 10.1972
201/6, 1.1960- Bussard	452, 1965- G-43	431	340 Yd, Zelenodolsk, USSR			12/1959	Board Guard 1965, stricken 6.1971
201/7, 1.1960- Weihe	453/423, 1965- G-18/G-41	432	340 Yd, Zelenodolsk, USSR			12/1959	Board Guard 1965, stricken 5.1975
201/8, 1.1960- Elster	431, 1965- G-61/G-43	433	340 Yd, Zelenodolsk, USSR			12/1959	Board Guard 1965, stricken 4.1972
201/9, 1.1960- Kranich	432, 1965- G-32/G-44	434	340 Yd, Zelenodolsk, USSR			12/1959	Board Guard 1965, stricken 4.1972
201/10, 1.1960- Möwe	433, 1965- G-63/G-45	435	340 Yd, Zelenodolsk, USSR			12/1959	Board Guard 1965, stricken 10.1972
Kormoran	411/424, 1965- G-44/G-46	441	340 Yd, Zelenodolsk, USSR			8/1960	Board Guard 1965, stricken 10.1976
Albatros	412, 1965- G-64/G-46	442	340 Yd, Zelenodolsk, USSR			8/1960	Board Guard 1965, stricken 4.1972

Technical data

Displacement standard, t	190
Displacement full, t	216
Length, m	41.7
Breadth, m	6.18
Draught, m	1.85
No of shafts	3
Machinery	3 40DM diesels
Power, h. p.	6600
Max speed, kts	27
Fuel, t	diesel oil
Endurance, nm(kts)	1500(12)
Armament	2 x 2 - 25/80 2M-3M, 4 x 5 RBU-1200 Uragan ASWRL, 2 DCR (24), 18 mines
Electronic equipment	Reya radar, Tamir-11 sonar
Complement	27

Standard scale images

Graphics

Project history

Former Soviet Project 201M submarine chasers.

Modernizations

None.

Naval service

: In 1965 all were transferred to Board Guard.
